LSIS SV-iG5A Series User Manual

9-34
z User display select
Group Display Parameter Name Setting Range Default Unit
Drive group
vOL [User display select] -
Function
group 2
H73 [Monitoring item select] - 0 ~ 2 0
 The selected item in H73- [Monitoring item select] can be monitored in vOL- [User display
select.
 If output power or torque is selected, Por or tOr will be displayed.
 H73: Select one of the desired item numbers.
H73 [Monitoring item
select]
0 Output voltage [V]
1
Output power
[kW]
2
Torque [kgf ⋅ m]
 Enter motor efficiency indicated on motor nameplate to H36 to display correct torque.
z Power on display
Group Code Parameter Setting range Initial
Function
group 2
H72 [Power on display] 0
Frequency command (0.00)
0
`
1
Accel time (ACC)
2
Decel time (DEC)
3
Drive mode (drv)
4
Frequency mode (Frq)
5
Multi-step frequency 1(St1)
6
Multi-step frequency 2(St2)
7
Multi-step frequency 3(St3)
8
Output current (CUr)
9
Motor rpm (rPM)
10
Inverter DC link voltage (dCL)
11
User display select (vOL)
12
Fault display 1(nOn)
13
Operating direction select (drC)
14
Output current 2
15
Motor rpm 2
16
Inverter DC link voltage 2
17
User display select 2
 Select the parameter to be displayed on the keypad when Power ON.
 The output current, motor rpm, DC link voltage and User display select are displayed
directly when 14~17 are set.
