LSIS SV-iG5A Series User Manual

5-24
LED
display
Address
for
commun
ication
Paramet
er name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
I56 A438 [Fault
relay
output]
0 ~ 7 When
setting the
H26–
[Number of
auto
restart try]
When the
trip other
than low
voltage trip
occurs
When the
low voltage
trip occurs
2 O 9-7
Bit 2 Bit 1 Bit 0
0 - - -
1- -
3
2-
3
-
3-
3 3
4
3
- -
5
3
-
3
6
3 3
-
7
3 3 3
I57
A439 [Output
terminal
select
when
commun
ication
error
occurs]
0 ~ 3 Multi-function
relay
Multi-function
output terminal
0 O 9-12
Bit 1 Bit 0
0- -
1-
3
2
3
-
3
3 3
I59 A43B [Commu
nication
protocol
select]
0 ~ 1 Set communication protocol. 0 X 11-2
0 Modbus RTU
1 LS BUS
I60 A43C [Inverter
number]
1 ~ 250 Set for RS485 communication 1 O 11-2
I61 A43D [Baud
rate]
0 ~ 4 Select the Baud rate of the RS485. 3 O 11-2
0 1200 [bps]
1 2400 [bps]
2 4800 [bps]
3 9600 [bps]
4 19200 [bps]
I62 A43E [Drive
mode
select
after
loss of
frequenc
y
comman
d]
0 ~ 2 It is used when freq command is given via
V1 /I terminal or RS485.
0 O 10-7
0 Continuous operation at the frequency
before its command is lost.
1 Free Run stop (Output cut-off)
2 Decel to stop
I63 A43F [Wait
time
after
loss of
frequenc
y
comman
d]
0.1 ~ 120
[sec]
This is the time inverter determines
whether there is the input frequency
command or not. If there is no frequency
command input during this time, inverter
starts operation via the mode selected at
I62.
1.0 O 10-7
