Page #32 background imageLoading...
Page #32 background image
32
Contact
Point
Q1
Multi-function
terminal
(open
collector)
DC 26V, below 100mA
EG
Common
terminal for
open
collector
External power supply common earth terminal of
the open collector
24
Exterior 24V
power
Maximum output current: 150mA
A1,
B1,C
1
Fault signal
output
Protection function is activated to break output.
(below AC 250V 5A, DC 30V 5A)
Fault signal: A1-C1 electrified (B1-C1
unelectrified)
Normal signal: B1-C1 electrified (A1-C1
unelectrified)
A2,
C2
Multi-function
relay 2
output A
contact
point
Output the signal while running. User defined
multi-function output terminal.
(below AC 250V 5A, DC 30V 5A)
S+,S-
,CM
RS-485
signal input
terminal
RS-485 signal line
(see Chapter 11 Communication Function of the
manual.)
