Chapter 6 CPU Functions
6- 17
It monitors system information of XGB series system.
(1) Clicking『Monitor』 displays the following sub-menus.
(2) Items and descriptions
Designate the start and stop of monitor.
Pause monitoring if a preset value of device
corresponds to condition.
Monitor resumes;
clicking for resume.
Change the present value of currently selected
device.
Monitor general system information.
Monitor by device (type).
Monitor trend of device set in the system.
For details, refer to
XG5000 Users Manual.
Monitor the value of device set when an event set
by a user occurs.
Trace the value of device.
