Chapter 1 Introduction
1-2
1.2 Features
The features of XGB system are as follows.
(1) The system secures the following high performances.
(a) High Processing Speed
(b) Max. 284 I/O control supporting small & mid-sized system implementation
Item
Type
Reference
XBC-DRxxE
XBC-DxxxS(U)
Operation processing
speed
0.24 ㎲ / Step
94ns / Step
-
Max IO contact point
38 points
284 points
In case of using option
module 4 points
(Coming soon)
Program capacity
4kstep
15kstep
-
Max. no. of expanded
stage
Option module 2
stages
7 stages (including option
module 2 stages)
-
(c) Enough program capacity
(d) Expanded applications with the support of floating point.
(e) XBC-DRxxE is expressed as “E” type and XBC-DxxxS(U) is expressed as “S(U)” type.
(2) Compact : the smallest size comparing to the same class model of competitors.
(a) Compact panel realized through the smallest size.
(Unit: mm)
Item
Type
Size (W * H * D)
Reference
Basic unit
XBC-Dx20S
135*90*64
“S” type
XBC-Dx30S
XBC-Dx20SU
“SU” type
XBC-Dx30SU
XBC-Dx40SU
161 * 90 * 64
XBC-Dx60SU
210 * 90 * 64
XBC-Dx10E
100*90*64
“E” type
XBC-Dx14E
XBC-Dx20E
135*90*64
XBC-Dx30E
Extension module
XBE-,XBF-,XBL-
20 * 90 * 60
Basis of minimum size
(3) Easy attachable/extensible system for improved user convenience.
(a) By adopting a removable terminal block connector (M3 X 6 screw), convenience of wiring may be
increased. (“S(U)” type main unit)
(b) By adopting connector coupling method, modules may be easily connected and separated.
(4) Improved maintenance ability with kinds of register, RTC option, comment backup and etc
(a) Convenient programming environment by providing analogue register and index register.
(b) Improved maintenance ability by operating plural programs and task program through module program.
(c) Built-in Flash ROM enabling permanent backup of program without any separate battery.
