Chapter 7 Input/Output Specifications
7-71
7.8 IO Wiring by Using Smart Link Board
7.8.1 Smart link board
Easy wiring is available by connecting the IO connector with smart link board.
The available smart link and IO cable are as follows.
XGB
Smart link
Connection cable
Item
Model
Model
No. of
Pin
Model
Length
Contents
Main unit
XBM-
DN32S
SLP-
T40P
40
SLT-CT101-
XBM
1m
For main unit connection
(20Pin + 20Pin)
XBM-
DN16S
Expansion
module
XBE-
DC32A
SLP-
T40P
40
SLT-CT101-
XBE
1m
For expansion module
connection (40Pin)
XBE-
TN32A
SLP-
T40P
40
SLT-CT101-
XBE
1m
SLP-
RY4A
40
SLP-CT101-
XBE
1m
For expansion module
connection (40Pin)
Exclusive for relay built-in
SLP type
It describes wring of XGB, SLP-T40P and SLT-CT101-XBM.
For wring of other smart link boards or XGB extension module, refer to XGB user manual for hardware.
1) SLT-T40P terminal array
Terminal array of SLP-T40P is as follows.
Item
Specification
Rated voltage
AC/DC 125[V]
Rated current
Max. 1[A]
Withstanding
voltage
600V 1min
Insulation
resistor
100 ㏁ (DC500V)
Cable
specification
1.25[㎟] or below
Terminal/screw
M3 X 8L
Torque
6.2 ㎏f.㎝ or
above
Terminal
material
PBT, UL94V-0
Weight
186g
