4.3 Power Supply Specifications

It describes the power supply specification of main unit.

Items

Specification

XBC-

Dx10/14E

XBC-

Dx20/30E

XBC-

Dx20S(U)

XBC-

Dx30S(U)

XBC-

Dx40SU

XBC-

Dx60SU

Input

Rated voltage

(UL warranty voltage)

AC 100 ~ 240 V

Input voltage range

AC85~264V(-15%, +10%)

Inrush current

50A

Peak

or less

Input current

0.5A or less (220V), 1A or less (110V)

Efficiency

65% or more

Permitted momentary

power failure

Less than 10 ㎳

Output

Rated

output

DC5V

500mA

800mA

1.5A

2.0A

2.5A

DC24V

0.2A

0.3A

0.5A

Output voltage ripple

DC5V (±2%)

Power supply status indication

LED On when power supply is normal

Cable specification

0.75 ~ 2 mm

* Use the power supply which has 4 A or more fuse for protecting power supply.
