If higher pulse than high speed counter input limit is inputted, 「abnormal operation stop」 error
may occur because MPU processing time increases to count fast and memory becomes full.
When using high speed counter, consider this.
Classification
Description
“E” type “S(U)” type
Count Enable To be set through program (count available only in enable status)
To be set through terminal (contact) or program
Auxiliary mode
Count Latch
Count per unit time (time setting value: 1~60,000ms)
(2) Counter/Preset input specification
Classification Spcification
Input voltage
24V DC (20.4V ~ 28.8V)
Input current 4㎃
On guranteed voltage (min.) 20.4V
Off guranteed voltage (max.) 6V
