Chapter 4 RTD Input Module (XBF-RD04A, XBF-RD01A)
4.2.2 Performance specifications
Here describes general specifications of RTD input module.
Item
Specifications
XBF-RD04A XBF-RD01A
No. of input channel 4 channels One channel
Input sensor
type
PT100 JIS C1604-1997
JPT100 JIS C1604-1981 , KS C1603-1991
Temperature
input range
PT100 -200 ~ 600℃
JPT100 -200 ~ 600 ℃
Digital output
PT100 -2000 ~ 6000
JPT100 -2000 ~ 6000
Scaling display
0 ~ 4000
Accuracy
Normal
temp.(25 ℃)
Within ±0.3%
Full temp.(0~55
Within ±0.5%
Conversion speed 40ms / channel
Insulation
Non-insulation
Terminal to PLC
Power
Insulation (Photo-Coupler)
Terminal block 15-point terminal block
I/O points occupied Fixed type: 64 points
Wiring method 3-wire
Max. number of equipment
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Function
Filtering Digital filter (160 ~ 64000ms)
Alarm Disconnection detection
Current
consumption
Inner DC5V 100㎃
external DC24V 100㎃
Weight 63g
4 - 3
