LSIS XBF-AH04A

XGB Analog edition manual
14.2 Specifications
14.2.1 General specifications
General specifications are as follows.
No. Item Specifications
Related
specifications
1
Ambient
temperature
0℃∼+55℃
-
2
Storage
temperature
-25℃∼+70℃ -
3
Ambient
humidity
5 ~ 95%RH (Non-condensing) -
4 Storage humidity 5 ~ 95%RH (Non-condensing) -
5
Vibration
resistance
Occasional vibration - -
Frequency Acceleration Amplitude How many times
IEC61131-2
5 ≤ f < 8.4 ㎐
-
3.5 ㎜
10 times each
directions
(X, Y and Z)
8.4 ≤ f ≤ 150 ㎐ 9.8 ㎨ (1G) -
For continuous vibration
Frequency Acceleration Amplitude
5 ≤ f < 8.4 ㎐ - 1.75 ㎜
8.4 ≤ f ≤ 150 ㎐ 4.9 ㎨ (0.5G) -
6
Shock resistance
•
Peak acceleration: 147 m/s
2
(15G)
•
Duration: 11ms
•
Half-sine, 3 times each direction per each axis
IEC61131-2
7 Noise resistance
Square wave
Impulse noise
AC: ± 1,500V
DC: ± 900V
LSIS standard
Electrostatic
discharge
Voltage : 4kV (contact discharging)
IEC 61131-2,
IEC 61000-4-
2
Radiated
electromagnetic
field noise
80 ~ 1,000 MHz, 10V/m
IEC 61131-2,
IEC 61000-4-
3
Fast transient
/bust noise
Segment
Power supply
module
Digital/analog input/output
communication interface
IEC 61131-2,
IEC 61000-4-
4
Voltage 2kV 1kV
8
Environment Free from corrosive gasses and excessive dust
-
9
Altitude Up to 2,000 ms
-
10
Pollution degree Less than equal to 2
-
11
Cooling Air-cooling
-
14 - 2
