6.13 Troubleshooting
This section describes methods for identifying the troubles which may occur during the
operation of analog I/O module, and their solutions.
6.13.1 LED Indication for Error
An analog I/O module has INPUT LED and OUTPUT LED to indicate error status of the module.
Classification
Normal
State
Channel Open
(Input)
Parameter
Setting Error
Module H/W Failure
(Serious Failure)
INPUT LED On Flickering 1s intervals
Flickering 1s intervals
(input parameter setting
error)
Flickering 0.2s
intervals
OUTPUT LED On N/A
Flikering at 1s intervals
(output parameter setting
error)
Flickering 0.2s
intervals
Module
Behavior
All functions
are normal
All functions are
performed. Indicates
min. input value
All functions work at
default parameter setting
Module cannot
function
Action
-
Check input wire
Check parameter setting
Request for A/S
6.13.2 Checking Module Condition
XG5000’s system monitor enables verification of the analog I/O module conditions (module type,
module information, OS version).
(1) Procedure
The verification can be done in 2 ways;
(a) [Monitor] -> [System Monitor] -> mouse right click on module icon -> [Module Information]
(b) [Monitor] -> [System Monitor] -> double click module icon.
(2) Module Information
(a) Module type: shows the information on the present module.
(b) Module information: shows the OS version of the module.
(c) OS version: shows release date of Module OS.
6 - 46
