LSIS XBF-AH04A

XGB Analog edition manual
5.6 Configuration and Function of Internal Memory
It describes the configuration and function of internal memory.
5.6.1 Data I/O area (U device)
(1) Data sent from module to XGB main unit (XGB PLC input area, read only)
Device
assignment
Type Comment Content R/W
Signal
direction
U0x.00.0
BIT
CH 0 offset/gain adjustment error
On: error, Off:
normal
R
TC→CPU
U0x.00.1
BIT
CH 1 offset/gain adjustment error
R
U0x.00.2
BIT
CH 2 offset/gain adjustment error
R
U0x.00.3
BIT
CH 3 offset/gain adjustment error
R
U0x.00.D
BIT
Module offset/gain backup error
R
U0x.00.E
BIT
Module H/W error
R
U0x.00.F BIT Module Ready
On: ready
Off: not ready
R
U0x.01.0
BIT
CH 0 running
Channel running
On: run, Off: stop
R
TC→CPU
U0x.01.1
BIT
CH 1 running
R
U0x.01.2
BIT
CH 2 running
R
U0x.01.3
BIT
CH 3 running
R
U0x.01.4
BIT
CH 0 disconnection
Thermocouple
sensor
On: disconnection,
Off: normal
R
U0x.01.5
BIT
CH 1 disconnection
R
U0x.01.6
BIT
CH 2 disconnection
R
U0x.01.7
BIT
CH 3 disconnection
R
U0x.01.8
BIT
CH 0 setting error
Parameter setting
On: setting error
Off: setting normal
R
U0x.01.9
BIT
CH 1 setting error
R
U0x.01.A
BIT
CH 2 setting error
R
U0x.01.B
BIT
CH 3 setting error
R
U0x.04
WORD
CH 0 temp. conversion value
Temp. conversion
value
(Measured
temp.×10)
R
TC→CPU
U0x.05
WORD
CH 1 temp. conversion value
R
U0x.06
WORD
CH 2 temp. conversion value
R
U0x.07
WORD
CH 3 temp. conversion value
R
U0x.08
WORD
CH 0 scaling operation value
Range with sign:
-32768~32767
Range without sign:
0~65535
R
TC→CPU
U0x.09
WORD
CH 1 scaling operation value
R
U0x.10
WORD
CH 2 scaling operation value
R
U0x.11
WORD
CH 3 scaling operation value
R
U0x.12
WORD
CH 0 min. temp. conversion value
Temp. conversion
min./max.
accumulation
R
TC→CPU
U0x.13
WORD
CH 0 max. temp. conversion value
R
U0x.14
WORD
CH 1 min. temp. conversion value
R
U0x.15
WORD
CH 1 max. temp. conversion value
R
U0x.16
WORD
CH 2 min. temp. conversion value
R
U0x.17
WORD
CH 2 max. temp. conversion value
R
U0x.18
WORD
CH 3 min. temp. conversion value
R
U0x.19
WORD
CH 3 max. temp. conversion value
R
※ ‘x’ means slot no. where module is installed.
Ex.) U02.04: no.2 slot channel 0 temp. conversion value (word)
5 - 36
