LSIS XBF-AH04A

XGB Analog edition manual
(3) Data sent from module to XGB main unit (IEC type)
(XGB PLC input area, read only)
Device
assignment
Type Comment Content R/W
Signal
direction
%UX0.x.0
BIT
CH 0 offset/gain adjustment error
On: error
Off: normal
R
TC→CPU
%UX0.x.1
BIT
CH 1 offset/gain adjustment error
R
%UX0.x.2
BIT
CH 2 offset/gain adjustment error
R
%UX0.x.3
BIT
CH 3 offset/gain adjustment error
R
%UX0.x.13 BIT Module offset/gain backup error R
%UX0.x.14
BIT
Module H/W error
R
%UX0.x.15 BIT Module Ready
On: ready
Off: not ready
R
%UX0.x.16
BIT
CH 0 running
Channel running
On: run, Off: stop
R
TC→CPU
%UX0.x.17
BIT
CH 1 running
R
%UX0.x.18
BIT
CH 2 running
R
%UX0.x.19
BIT
CH 3 running
R
%UX0.x.20
BIT
CH 0 disconnection
Thermocouple
sensor
On: disconnection,
Off: normal
R
%UX0.x.21
BIT
CH 1 disconnection
R
%UX0.x.22
BIT
CH 2 disconnection
R
%UX0.x.23
BIT
CH 3 disconnection
R
%UX0.x.24
BIT
CH 0 setting error
Parameter setting
On: setting error
Off: setting normal
R
%UX0.x.25
BIT
CH 1 setting error
R
%UX0.x.26
BIT
CH 2 setting error
R
%UX0.x.27
BIT
CH 3 setting error
R
%UW0.x.4
WORD
CH 0 temp. conversion value
Temp. conversion
value
(Measured temp.×10)
R
TC→CPU
%UW0.x.5
WORD
CH 1 temp. conversion value
R
%UW0.x.6
WORD
CH 2 temp. conversion value
R
%UW0.x.7
WORD
CH 3 temp. conversion value
R
%UW0.x.8
WORD
CH 0 scaling operation value
Range with sign:
-32768~32767
Range without sign:
0~65535
R
TC→CPU
%UW0.x.9
WORD
CH 1 scaling operation value
R
%UW0.x.10
WORD
CH 2 scaling operation value
R
%UW0.x.11
WORD
CH 3 scaling operation value
R
%UW0.x.12
WORD
CH 0 min. temp. conversion value
Temp. conversion
min./max.
accumulation
R
TC→CPU
%UW0.x.13
WORD
CH 0 max. temp. conversion value
R
%UW0.x.14
WORD
CH 1 min. temp. conversion value
R
%UW0.x.15
WORD
CH 1 max. temp. conversion value
R
%UW0.x.16
WORD
CH 2 min. temp. conversion value
R
%UW0.x.17
WORD
CH 2 max. temp. conversion value
R
%UW0.x.18
WORD
CH 3 min. temp. conversion value
R
%UW0.x.19
WORD
CH 3 max. temp. conversion value
R
※ ‘x’ means slot no. where module is installed.
Ex.) %UW0.2.4: no.2 slot channel 0 temp. conversion value (word)
5 - 38
