LSIS XBF-AH04A

XGB Analog edition manual
1 - 2
Classification
Name
No. of
channel
Range
Resolution
Characteristic
Analog combo
(voltage/current
I/O)
XBF-AH04A
2(Input)
2(Output)
4~20㎃
0~20㎃
5.0 ㎂
1.Range selection by external switch
and parameter setting
2.Filter function, averaging function
3.Specifies output when error or CPU
STOP
4. Uses external DC24V
1~5V
0~5V
1.25 ㎷
0~10V
2.5 ㎷
Analog Input
Option Board
XBO-AD02A
2
4~20㎃
6.25 ㎂
1. Parameter setting
2. Filter function, average function
3. Internal VDD 5V
0~20㎃
5.0 ㎂
Analog Output
Option Board
XBO-DA02A
2
0~10V
2.5 ㎷
Analog IO
Option Board
XBO-AH02A
1(Input)
4~20㎃
6.25 ㎂
1. Parameter setting
2. Filter function, average function
3. Internal VDD 5V
0~20㎃
5.0 ㎂
1(Output)
0~10V
2.5 ㎷
RTD Input
Option Board
XBO-RD01A
1
PT100
JPT100
0.1℃
1. Internal VDD 5V
2. Filter function, average function
Thermocouple
Input Option
Board
XBO-TC02A
2
K / J
Note2)
1. Internal VDD 5V
2. Filter function, average function
Note2) for more detail on Thermocouple Input Option Board resolution, refer to Ch.12.5 accuracy
