Chap. 6 Analog I/O Module (XBF-AH04A)
(3) DC 1 ~ 5V Range Output
Digital Input
Range
Analog Output Voltage (V)
1V less
1
2
3
4
5
5V over
Unsigned Value
(0 ~ 4000)
0 less 0 1000 2000 3000 4000 4000 over
Signed Value
(-2000 ~ 2000)
-2000 less -2000 -1000 0 1000 2000 2000 over
Precise Value
(100 ~ 500)
100 less 100 200 300 400 500 500 over
Percentile
Value(0 ~ 1000)
0 less 0 250 500 750 1000 1000 over
(4) DC 0 ~ 5V Range Output
Digital Input
Range
Analog Output Voltage (V)
0V less
0
1.25
2.5
3.75
5
5V over
Unsigned Value
(0 ~ 4000)
0 less 0 1000 2000 3000 4000 4000 over
Signed Value
(-2000 ~ 2000)
-2000 less -2000 -1000 0 1000 2000 2000 over
Precise Value
(0 ~ 500)
0 less 0 125 250 375 500 500 over
Percentile
Value(0 ~ 1000)
0 less 0 250 500 750 1000 1000 over
(5) DC 0 ~ 10V Range Output
Digital Input
Range
Analog Output Voltage (V)
0V less
0
2.5
5
7.5
10
10V over
Unsigned Value
(0 ~ 4000)
0 less 0 1000 2000 3000 4000 4000 over
Signed Value
(-2000 ~ 2000)
-2000 less -2000 -1000 0 1000 2000 2000 over
Precise Value
(0 ~ 1000)
0 less 0 250 500 750 1000 1000 over
Percentile
Value(0 ~ 1000)
0 less 0 250 500 750 1000 1000 over
6 - 9
