(3) Common specification (XBF-TC04S / XBF-TC04B)
Items
Specification
Insulation
Insulation
method
Terminal – inner
circuit
Photo-coupler insulation
Terminal – operating
power
DC/DC converter insulation
Between channels
Photomos relay insulation
Dielectric withstand voltage
400 V AC, 50/60 Hz, 1min,
leakage current 10㎃ or below
Insulation resistance
500 V DC, 10 MΩ or below
Terminal block
11 point terminal
I/O occupied points
64 points
Max. number of equipment
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Additional
function
Filter process
Digital filter (200 ~ 64,000㎳)
Average process
Time average (400~64,000㎳)
Count average (2~64,000 times)
Moving average (2~100)
Alarm
Disconnection detection
Max./Min. display
Display Max./Min.
Scaling function
Signed scaling / Unsigned scaling
Consumption
current
Inner DC5V
100㎃
External DC24V
100㎃
Weight
63g
