XGB Analog edition manual
1 - 12
(2) Output performance specification
Items
XBF-AH04A
No. of output channel
2 channels
Analog
output
range
Type
Voltage
Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
(Load resistor: 2kΩ or above)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Load resistor 510 Ω or less)
Input range can be set through external voltage/current selector switch after
setting at user program or I/O parameter per input channel
Digital
input
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise
value
100 ~ 500 (DC 1 ~ 5V)
0 ~ 500 (DC 0 ~ 5V)
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20㎃)
0 ~ 2000 (DC 0 ~ 20㎃)
Percentile
value
0 ~ 1000
Max. resolution
1/4000
1.25㎷ (DC 1~5V, 0~5V)
2.5㎷ (DC 0~10V)
5㎂ (DC4~20㎃, 0~20㎃)
Precision
±0.5% or less
Max. conversion speed
1ms/channel
Absolute max. output
DC ±15V
DC 25㎃
Additional function
Function setting channel output status
(Can select one among Previous, Minimum, median, maximum)
(3) I/O common performance specification
Items
XBF-AH04A
Insulation method
Photo coupler insulation between I/O terminal and PLC power (not
insulated between channels)
I/O terminal block
11 points terminal block
No. of I/O occupation point
Fixed type: 64 points
Max. number of equipment
7 (when using XBM-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Consumption
current
Internal (DC 5V)
120㎃
External (DC 24V)
130㎃
Weight
73g
