(2) DC 0 ~ 20mA Range Input
Digital
Output Range
Analog Input Current (mA)
-0.24
0
5
10
15
20
20.23
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(0 ~ 2000)
-24 0 500 1000 1500 2000 2023
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
(3) DC 0 ~ 10V Range Input
Digital
Output Range
Analog Input Voltage (V)
-0.12
0
2.5
5
7.5
10
10.11
Unsigned Value
(0 ~ 4000)
-48 0 1000 2000 3000 4000 4047
Signed Value
(-2000 ~ 2000)
-2048 -2000 -1000 0 1000 2000 2047
Precise Value
(0 ~ 1000)
-12 0 250 500 750 1000 1011
Percentile
Value(0 ~ 1000)
-12 0 250 500 750 1000 1011
