LSIS XBF-AH04A

XGB Analog edition manual
1 - 14
1.2.7 Analog Output Option Board
Item
XBO-DA02A
No. of channels
2 channels
Analog
output
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Load resistance: 2㏀ or more)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Load resistance: 450Ω)
Output range can be set at user program or I/O parameter for each
channel
Digital
input
Type
12-bit binary data
Range
Unsigned
value
0~4000
Signed value
-2000 ~ 2000
Precise value
0 ~ 1000 (DC0~10V)
400 ~ 2000 (DC4~20㎃)
0 ~ 2000 (DC0~20㎃)
Percentile value
0 ~ 1000
Maximum resolution
1/4000 (DC 4 ~ 20mA: 1/3200)
2.5㎷ (DC 0 ~ 10V)
5㎂ (DC 0~20㎃)
6.25㎂ (DC 4~20㎃)
Accuracy
±1.0% or less
Maximum conversion speed
1㎳/channel + scan time
Additional function
Channel output state setting (former, min, middle, max value)
Gain adjustment function
Insulation method
no insulation between analog output channels
no insulation between output terminal and PLC main unit
I/O terminal
5-point terminal block
Power supply
Internal 5V
I/O points occupied
Fixed type: 64 points
Supply power
Internal DC5V
Current consumption
150㎃
Weight
20g
