8.11.2 Operation Parameter Setting Area
The operation parameter setting area of the analog mix module is as follows.
Memory
Add.
Description Setting R/W Command
0 Enable channel Bit Off (0): disable, Bit ON (1): enable R/W
PUT/GET
1 Input range setting
Input range setting (4 bit per channels)
0: 4 ~ 20 
1: 0 ~ 20 
2: 0 ~ 10 V
R/W
2 Output data type setting
Output data type setting
(4 bit per channels)
0: 0 ~ 4000
1: -2000 ~ 2000
2: Precise value
3: 0 ~ 1000
- In case of precise value
4 ~ 20 : 400 ~ 2000
0 ~ 20 : 0 ~ 2000
0 ~ 10 V: 0 ~ 1000
R/W
3
Input channel 0 count
average value setting
0 or 2 ~ 64000 [times]
R/W
4
Input channel 1 count
averaging value setting
R/W
9
Input channel 0 gain
weighting
-40~40
R/W
10
Input channel 1 gain
weighting
R/W
13 Setup error information
10#: input ch range setting error
20#: input ch data type setting error
30#: input ch average value setting error
40#: input ch gain weighting setting error
(#: channel number)
R GET
