XGB Analog edition manual
1 - 16
(3) I/O Common performance specification
Items
XBO-AH02A
Insulation method
Non-insulation betweens analog I/O channels
Non-insulation between I/O terminal and PLC main unit
I/O terminal
5-point terminal block
I/O occupation point
Fixed type: 64 points
Max. installation count
1(when using XBC-DR10E/DR14E type)
2(when using XBC-DR20E/DR30E type)
2(when using XBC-DxxxS/SU type)
Supply power
Internal DC5V
Consumption current
150㎃
Weight
20g
1.2.9 RTD Input Option Board
Items
XBO-RD01A
No. of input channels
One channel
Input sensor
type
PT100
JIS C1604-1997
JPT100
JIS C1604-1981 , KS C1603-1991
Temperature
input range
PT100
-200 ~ 600℃
JPT100
-200 ~ 600℃
Digital output
PT100
-2000 ~ 6000
JPT100
-2000 ~ 6000
Accuracy
Within ±1.0%
Conversion speed
25m/1 channel
Insulation
Channel to
Channel
Non-insulation
Terminal to PLC
Power
Insulation (Photo-Coupler)
Terminal block
5-point terminal block
I/O points occupied
Fixed type: 64 points
Max. number of equipment
1 (when using XBC-DR10E/DR14E type)
2 (when using XBC-DR20E/DR30E type)
2 (when using XBC-DxxxS type)
Wiring method
3-wire type
Function
Averaging
Count averaging function
Alarm
Disconnection detection
Supply power
Internal DC5V
Consumption current
30㎃
Weight
20g
