LSIS XBF-AH04A

Chapter 10 Analog I/O Option Board (XBO-AH02A)
10.7.4 Analog output wiring example
(1) Current output wiring example
V0+
I0+
V0+
I0+
COM
R
R
R
XBO-AH02A
INPUT
OUTPUT
510 or
less
Motor etc.
(2) Voltage output wiring example
INPUT
OUTPUT
2k or
above
Motor etc.
V0+
I0+
V0+
I0+
COM
R
R
R
XBO-AH02A
450 

2 

10 - 19
