Chapter 11 RTD Input Option Board (XBO-RD01A)
11.2.2 Performance specifications
Here describes general specifications of RTD input option board.
XBO-RD01A
No. of input channels One channel
Input sensor
type
PT100 JIS C1604-1997
JPT100 JIS C1604-1981 , KS C1603-1991
Temperature
input range
PT100 -200.0 ~ 600.0℃ (-328.0℉~1112.0℉)
JPT100 -200.0 ~ 600.0℃ (-328.0℉~1112.0℉)
Digital output
PT100 -2000 ~ 6000
JPT100 -2000 ~ 6000
Accuracy Within ±1.0%
Conversion speed 25ms/1Ch – note1)
Insulation
Channel to
Channel
Non-insulation
Terminal to
PLC Power
Insulation (Photo-Coupler)
Terminal block 5-point terminal block
I/O points occupied Fixed type: 64 points
Wiring method
3-wire type
Function
Averaging Count averaging function
Alarm Disconnection detection
Current
consumption
Inner DC5V 30㎃
Weight 20g
Note1) Conversion speed can be delayed because of scan delay per channel by XGB main unit
- In order to use analog input option board, the following version is needed.
Main unit Version information
XBC E type
V1.1 or above
XBC S type
V1.1 or above
XBC SU type
V1.0 or above
XEC E type
V1.0 or above
XEC SU type
V1.0 or above
XG5000
V.3.61 or above
