XGB Analog edition manual
11.14.2 Operation parameter setting area
Operation parameter setting areas of RTD input option board are as follows.
Memory
address
Contents Setting value R/W Instruction
0
Channel
enable/disable
setting
CH status setting
0: Stop
1: Run
R/W
PUT/GET
1
sensor type setting
Input range setting
0: PT100
1: JPT100
R/W
5
Temperature display
unit setting
Data type setting
0: Celsius
1: Fahrenheit
R/W
6
disconnection
information
0: Normal
1: Disconnection
R GET
14
Count average
value
0 or 2~64,000 R/W
PUT
GET
15 Error information
100: sensor type setting error
300: count average value setting error
R GET
11 - 22
