LSIS XBF-AH04A

XGB Analog edition manual
(7) The example of analog input 4-Wire sensor/transmitter wiring(The current input)
Use the I+ and COM terminal after connecting V+ with I+ terminal.
DC
+
-
4- Wire
Transmitter
XBF-AD04C
RUN
XBF-AD04C
DC24V
-10~10V
0~20mA
V0+
I0+
COM0
V1+
I1+
COM1
V2+
I2+
COM2
V3+
I3+
COM3
CH0
CH1
CH0-
CH2
CH3
CH0+
CH1-
CH1+
CH2-
CH2+
CH3-
CH3+
I0+
COM0
I1+
COM1
I2+
COM2
I3+
COM3
DC
+
-
4- Wire
Transmitter
DC
+
-
4- Wire
Transmitter
DC
+
-
4- Wire
Transmitter
DC24V+
DC24V-
PE
DC Power
(For analog module)
※ DC power for analog power supply have to connect DC24V- with PE.
13 - 20
