13.13.3 Check and Measure the breakdown
1) The LED is turned off.
The LED is turned off.
The analog module is installed on
correct position.
Install the analog module correctly.
No
Yes
I/O information is shown in XG5000
software.
Call our near agency or A/S center.
No
Yes
When the abnormal analog input
module is changed into normal one,
it operates well.
Yes
Call our near agency or A/S center.
2) The LED is flickering.
The LED is flikering.
The LED is flikering 1s intervals.
The wiring is normal.
Make wiring correctly by referring the
instructions.( Check disconnection)
No
Yes
The parameter setting is correct.
(Check 'PUT' )
The operation parameter is error.
Set correctly by referring parameter setting
rules from instructions.
(Check error code)
No
