Chapter14 Analog Output Module (XBF-DV04C/XBF-DC04C)
(3) DC 0 ~ 10V Output range
Digital input
Analog output voltage (V)
-0.12 0 2.5 5 7.5 10 10.119
Unsigned value
(-192 ~ 16,191)
-192 0 4,000 8,000 12,000 16,000 16,191
Signed value
(-8,192 ~ 8,191)
-8,192 -8,000 -4,000 0 4,000 8,000 8,191
Precise value
(-120 ~ 10,119)
-120 0 2,500 5,000 7,500 10,000 10,119
Percentile value
(-120 ~ 10,119)
-120 0 2,500 5,000 7,500 10,000 10,119
(4) DC -10 ~ 10V Output range
Digital input
Analog output voltage (V)
-10.24 -10 -5 0 5 10 10.239
Unsigned value
(-192 ~ 16,191)
-192 0 4,000 8,000 12,000 16,000 16,191
Signed value
(-8,192 ~ 8,191)
-8,192 -8,000 -4,000 0 4,000 8,000 8,191
Precise value
(-10,240 ~ 10,239)
-10,240 -10,000 -5,000 0 5,000 10,000 10,239
Percentile value
(-120 ~ 10,119)
-120 0 2,500 5,000 7,500 10,000 10,119
14 - 7
