LSIS XBF-AH04A

Chapter 15 PID Function (Built-in function)
15 - 39
2) _ATxx_T_s (Auto-tuning xx Loop operation cycle)
It sets/indicates the operation cycle of ‘xx’ th loop auto-tuning. The available scope is 100 ~
65,535.
3) _ATxx_MV_max, _ATxx_MV_min(max. MV, min. MV)
It sets max. MV and min. MV of ‘xx’ th loop respectively. If the max. MV is set lower than min.
MV, the auto-tuning loop generates an error and does not work.
4) _ATxx_PWM (AT output junction setting)
It sets the junction that PWM output of ‘xx’th loop is output. The PWM output junction is valid
only between H’20 ~ H’3F (hex). If any other value is entered, PWM output does not work.
5) _ATxx_PWM_Prd (PWM output cycle setting)
It sets the PWM output cycle of ‘xx’ th loop. The available scope is between 100 ~ 65,535 at the
unit of 0.1ms.
6) _ATxx_HYS_val (Hysterisis setting)
It sets the hysterisis of ‘xx’ th loop. For more information about hysterisis function, refer to 6.3.3
Auto-Tuning Parameter Setting. If it is set as 0, it does not work.
7) _ATxx_STATUS (Auto-tuning status)
It indicates the auto-tuning status of ‘xx’ th loop. If auto-tuning is in operation, it is 1;
if completed, it is 128. In any other cases, it shows 0.
Flag name
Address
IEC type address
Unit
Scope
_PIDxx_T_s
(Auto-tuning xx Loop operation cycle)
K1861+16*xx
%KW1861+16*xx
WORD
100 ~ 65,535
Flag name
Address
IEC type address
Unit
Scope
_PIDxx_MV_max (Max. MV)
K1862+16*xx
%KW1862+16*xx
INT
-32,768 ~ 32,767
_PIDxx_MV_min (Min. MV)
K1863+16*xx
%KW1863+16*xx
Flag name
Address
IEC type address
Unit
Scope
_AT00_PWM
(AT output junction setting)
K1864+16*xx
%KW1864+16*xx
WORD
H’20 ~ H’3F
Flag name
Address
IEC type address
Unit
Scope
_ATxx_PWM_Prd
(PWM output cycle setting)
K1865+16*xx
%KW1865+16*xx
WORD
100 ~ 65,535
Flag name
Address
IEC type address
Unit
Scope
_ATxx_HYS_val (Hysterisis setting)
K1866+16*xx
%KW1866+16*xx
WORD
0 ~ 65,535
Flag name
Address
IEC type address
Unit
Scope
_ATxx_STATUS
(Auto-tuning status)
K1867+16*xx
%KW1867+16*xx
WORD
Unavailable
