LSIS XBF-AH04A

Appendix 1
Appendix 1- 1
Appendix 1 Standard Resistor of RTD
Pt100Ω
-200
18.52
-100
60.26
56.19
52.11
48.00
43.88
39.72
35.54
31.34
27.10
22.83
0
100.00
96.09
92.55
88.22
84.27
80.31
76.33
72.33
68.33
64.30
Temp.(℃)
0
10
20
30
40
50
60
70
80
90
0
100.00
103.90
107.79
111.67
115.54
119.40
123.24
127.08
130.90
134.71
100
138.51
142.29
146.07
149.83
153.58
157.33
161.05
164.77
168.48
172.17
200
175.86
179.53
183.19
186.84
190.47
194.10
197.71
201.31
204.90
208.48
300
212.05
215.61
219.86
222.68
226.21
229.72
233.21
236.70
240.18
243.64
400
247.09
250.53
253.96
257.38
260.78
264.18
267.56
270.93
274.29
277.64
500
280.98
284.30
287.62
290.92
294.21
297.49
300.75
304.01
307.25
310.49
600
313.71
JPt100Ω
-200
17.14
-100
59.57
55.44
51.29
47.11
42.91
38.68
34.42
30.12
25.80
21.46
0
100.00
96.02
92.02
88.01
83.99
79.96
75.91
71.85
67.77
63.68
Temp.(℃)
0
10
20
30
40
50
60
70
80
90
0
100.00
103.97
107.93
111.88
115.81
119.73
123.64
127.54
131.42
135.3
100
139.16
143.01
146.85
150.67
154.49
158.29
162.08
165.86
169.63
173.38
200
177.13
180.86
184.58
188.29
191.99
195.67
199.35
203.01
206.66
210.3
300
213.93
217.51
221.15
224.74
228.32
231.89
235.45
238.99
242.53
246.05
400
249.56
253.06
256.55
260.02
263.49
266.94
270.38
273.8
277.22
280.63
500
284.02
287.4
290.77
294.12
297.47
300.8
304.12
307.43
310.72
314.01
600
317.28
