3.12.2 Setting area of operation parameters
XBF-DV04A
Address
(Dec)
Description
Details
Remarks
0
Set up the run channel
Bit On(1): Run
Bit Off(0): Stop
Read/Write
available
1
Set up the output voltage range
Bit (00): 0 ~ 10V
2
Set up the input data type
Bit (00): 0 ~ 4000
Bit (01): -2000 ~ 2000
Bit (10): 0 ~ 1000
Bit (11): 0 ~ 1000
3
Set up the output type of CH0
0: outputs the previous value
1: outputs the min. value of output range
2: outputs the mid. value of output range
3: outputs the max. value of output range
4
Set up the output type of CH1
5
Set up the output type of CH2
6
Set up the output type of CH3
11
CH0 setting error
Error code
Read
available
12
CH1 setting error
13
CH2 setting error
14
CH3 setting error
XBF-DC04A
Address
(Dec)
Description
Details
Remarks
0
Set up the run channel
Bit On(1): Run
Bit Off(0): Stop
Read/Write
available
1
Set up the output voltage range
Bit (00): 4 ~ 20mA
Bit (01): 0 ~ 20mA
2
Set up the input data type
Bit (00): 0 ~ 4000
Bit (01): -2000 ~ 2000
Bit (10): 400 ~ 2000/0 ~ 2000
Bit (11): 0 ~ 1000
3
Set up the output type of CH0
0: outputs the previous value
1: outputs the min. value of output range
2: outputs the mid. value of output range
3: outputs the max. value of output range
4
Set up the output type of CH1
5
Set up the output type of CH2
6
Set up the output type of CH3
11
CH0 setting error
Error code
Read
available
12
CH1 setting error
13
CH2 setting error
14
CH3 setting error
