Lucent Technologies Lineage
®
2000 50A -48V 364A-3 SR Series Rectifier
Issue 6 January 1997 Installation 5 - 11
5. Connect DMM to the RECT (+) and (-) test jack. The
meter reading represents the rectifier output voltage
produced with the DC OUTPUT circuit breaker in the OFF
position. (See notes below.) Adjust the VOLTS ADJ - FL
potentiometer using a jeweler's screwdriver until the
desired plant voltage level is obtained. The meter reading
should match the value read at the PLANT (+) and (-) test
jacks.
6. Repeat Steps 2-5 for all rectifiers to be put on line at this
time.
7. If the plant is not to be configured for equalize operation,
proceed to Step 16.
8. At the controller, put the rectifier in equalize mode. (See
controller product manual for details, if necessary.)
9. At the rectifier, verify that only the following LEDs are lit:
POWER ON, CB OFF, EQ. Check that OUTPUT
CURRENT display reads 00.0.
10. Connect DMM to the PLANT (+) and (-) test jacks on the
rectifier. If batteries are present or if other rectifiers in the
plant are ON and adjusted properly, the meter should read
the proper plant voltage. If there are no batteries or other
rectifiers ON, the meter should read zero.
Note
If plant voltage is present, the voltage appearing at the RECT
test jacks is never less than 1.5V below the plant voltage, even
with the rectifier turned off. When adjusting the rectifier, it
may take many turns before the voltage at the rectifier test
jacks begins to change.
Note
At this time do not close the DC OUTPUT circuit breaker.
Note
If LED’s status is not as specified, refer to Section 7,
Maintenance, for troubleshooting help.
