Lumel ND30 User Manual

ND30-09D 20 User's manual
Table 1
Item Parameter name Feature / value Description Default
settings
1 Connection wire 3 phase -4 wire
3 phase -3 wire
1 phase -2 wire
Type of power
network
3-phase 4-wire
3-phase 3-wire
1-phase 2-wire
3 phase -4
wire
2 Current input range 1A, 5A Input range: 1A or 5A 5A
3 Voltage input range 3x57.7/100 V;
3x230/400 V;
or
3x110/190 V;
3x400/690 V;
Choice of the
ranges depending
on the ordering
code
3x230/400 V
or
3x400/690 V
4 Voltage transformer
primary
1 .. 1245183 V 100
5 Voltage transformer
secondary
0.1 .. 01000.0 100.0
6 Current transformer
primary
1…20000 5
7 Current transformer
secondary
1…1000 5
8 Damend integ. time 15 min, 30 min,
60 min
Averaging time
active power P
DMD,
apparent power S
DMD,
current I DMD
15 min
9 AVG synchronization none, with RTC Averaging
synchronized with
the real-time clock
none
10 PT100 resist on inp 1 0000.00 Resistance value in

0.00 
11 PT100 resist on inp 2 0000.00 Resistance value in

0.00 
12 Voltage connector 2 U1, U2, U3 U1
13 Voltage connector 5 U1, U2, U3 U2
14 Voltage connector 8 U1, U2, U3 U3
15 Current connector 1-3 I1,-I1,I2,-I2,I3,-I3 I1
16 Current connector 4-6 I1,-I1,I2,-I2,I3,-I3 I2
17 Current connector7-9 I1,-I1,I2,-I2,I3,-I3 I3
18 Delete energy
counters
No, Active,
Reactive,
Apparent, All
No
19 Delete demand
values
No, Yes No
20 Default parameters No, Yes No
During changing the parameter, it is check if the value is in the range. If the set value
falls outside the allowable range, the value is set to the maximum value (when entered
value is too high) or minimum value (when it is too low).
