ND30-09D 11 User's manual
Current state of the archiving:
Black – archiving in a group enabled,
waiting for the archiving conditions to be
met.
Red – the archiving conditions have
been met and saving the records is in
progress.
White – archiving in a group disabled.
1st archiving group
2nd archiving group
Percentage of files archive memory
used
Green background Value in the range 0 ... 70%
Orange background 70% of files archive space
is full. It is recommended to
remove unnecessary files
via FTP.
Red background It is less than 7% of free
space in the files archive
memory left. Time to
completely use a the files
archive space is
approximately 14 days at 1
sec. interval. Immediately
delete any unnecessary
files via FTP.
Percentage of the archive copying
progress.
Blue flashing background Copying from internal
memory to files archive
memory in progress
6.2 Starting work
After switching the supply on, the meter displays the ND30 meter name,
version, current software version and MAC for the version with Ethernet and
then moves to the measurement mode and last saved page. Displayed
information:
ND30 v:1.00 – meter type, program version number
Bootloader v.01.05 – bootloader version number
U: 57.7/230.0 V – voltage versions
I: 1.0/5.0 A – current versions
MAC: AA:BB:CC:DD:EE:FF (for versions with Ethernet)
