Table 14
Register Description Default value
4146 Device address for Modbus TCP/IP protocol 1
4147 Modbus TCP port number 502
4145 Port closing time of Modbus TCP/IP service [s] 60
4144 The maximum simultaneous connections to Modbus
TCP/IP service
4
The device address is the address of the device for Modbus TCP/IP
protocol and is not a value equal to a address value for Modbus RS485
protocol (Modbus network address register 4100). Setting the parameter
"Device address for Modbus TCP/IP protocol" of the meter to the value
"255", the meter will skip the address analysis in the frame of Modbus
protocol (broadcast mode).
11 MAP OF ND30 METER REGISTERS
In the ND30 meter, data are placed in 16 and 32-bit registers. Process
variables and meter parameters are placed in the address area of registers
in a way depended on the variable value type. Bits in 16-bit register are
numbered from the youngest to the oldest (b0-b15). The 32-bit registers
contain numbers of float type in IEEE-754 standard. 3210 byte sequence -
the oldest is sent first.
Table 15
Address
range
Value
type
Description
4000 – 4159
Integer
(16 bits)
Value set in the 16-bit register. Registers for meter
configuration. Description of registers is shown in Table 16.
Registers for writing and readout.
4200 – 4260
Integer
(16 bits)
Value set in the 16-bit register. Registers for configuration
of programmable group of registers for readout.
Description of registers is shown in Table 15. Registers for
writing and readout.
4300 - 4388
Integer
(16 bits)
Value set in the 16-bit register. Registers for displayed
pages configuration. Description of registers is shown in
Table 19. Registers for writing and readout.
4400- 4440
Integer
(16 bits)
Value set in the 16-bit register. Status registers, energy
value, MAC address of the meter, configuration data.
Description of registers is shown in Table 20. Readout
registers.
6000 – 6922
Float
(2x16 bits)
Value is set in the two following 16-bit registers. Registers
contain exactly the same data, as 32-bit registers of 7500 –
7953 range. Readout registers. Bytes sequence (1-0-3-2)
7000 - 7118
Float
(2x16 bits)
Content of the registers set in the registers 4200 – 4359.
Bytes sequence (3-2-1-0)
