Lumel ND30 User Manual

ND30-09D 82 User's manual
2 relays, 1 analog output, 2 Pt100 inputs 2
Interfaces
RS485 1
RS485 and Ethernet interface, internal memory file system 2
Supply voltage:
85..253 V a.c., 90..300 V d.c. 1
20..40 V a.c., 20..60 V d.c. 2
Version
standard 00
supervisory relay SR
custom-made* XX
Language version
Polish P
English E
other* X
Acceptance tests
without extra requirements 0
with quality inspection certificate 1
with calibration certificate 2
acc. to customer’s request* X
* only after agreeing with a manufacturer
ORDERING CODE EXAMPLE, the code ND30-1 2 2 1 00 E 0 means:
ND30 – ND30 meter,
1 – input voltage 3 x 57.7/100 V, 3 x 230/400 V,
2 – 2 relays, 1 analog output 0..20 mA, 2 inputs Pt100
2 – RS-485 and Ethernet, internal memory file system
1 – supply voltage: 85..253 V a.c., 90..300 V d.c.
00 – standard version
E – English language version
0 – without extra requirements.

Lumel ND30 Specifications

General

Brand	Lumel
Model	ND30
Category	Measuring Instruments
Language	English
