ND30-09D 76 User's manual
b)
Fig. 32. View of the window a) logging on, b) website upgrade file
12.2 Firmware update - main program of the meter
A feature implemented in the ND30 meters enables to upgrade firmware
using a PC with eCon software installed. Free eCon software and the
update files are available at www.lumel.com.pl. Upgrade of meter software
(firmware) can be done via RS-485 interface. Go to LUMEL UPDATER tab
to upgrade.
a) b)
Fig. 33. Program window view: a) eCon, b) software upgrade
Note: Software update automatically resets meter settings to default
settings, so it is recommended to save meter settings using eCon software
before upgrading.
After launching eCon software, set in the settings required serial port, baud
rate, mode and address of the meter. Next, select the ND30 meter and click
Config. Click the down arrow icon to read all of the settings then the disk
icon to save the settings to a file (required to restore the settings later). After
selecting the option Update firmware (in the upper right corner of the
screen) the window Lumel Updater (LU) will be opened – Fig. 33b. Click
Connect. The Messages information window displays information
concerning upgrade process. If the port is opened correctly, a Port opened
message appears. Upgrade mode is enabled using either of the two
methods: remotely via LU (using LPCon settings: address, mode, baud rate,
