Lumel ND30 User Manual

ND30-09D 51 User's manual
7200 – 7318
Float
(2x16 bits)
Content of the registers set in the registers 4200 – 4359.
Bytes sequence (1-0-3-2)
7400 - 7459
Float
(32 bits)
Content of the registers set in the registers 4200 – 4359.
Values set in one 32-bit register.
7500 – 7961
Float
(32 bits)
Values set in one 32-bit register. Description of registers is
shown in Table 21. Readout registers.
8000 - 8922
Float
(2x16 bits)
Value is set in the two following 16-bit registers. Registers
contain exactly the same data, as 32-bit registers of 7500 –
7953 range. Readout registers. Bytes sequence (3-2-1-0)
Table 16
Register
address
Opera
tions
Range Description Default
4000 RW 0…9999 Protection - password 0
4001 RW 0 .. 1
Type of connection
0 - 3Ph/4W
1 - 3Ph/3W
2 - 1Ph/2W
0
4002 RW 0 .. 2
Voltage on terminal 2
0 - first L1 phase voltage
1 - second L2 phase voltage
2 - third L3 phase voltage
0
4003 RW 0 .. 2
Voltage on terminal 5
0 - first L1 phase voltage
1 - second L2 phase voltage
2 - third L3 phase voltage
1
4004 RW 0 .. 2
Voltage on terminal 8
0 - first L1 phase voltage
1 - second L2 phase voltage
2 - third L3 phase voltage
2
4005 RW 0..5
Current on terminals 1, 3:
0 - first phase I
L1
current
1 - reversed direction of the current of phase L1:
-I
L1
2 - second phase I
L2
current
3 - reversed direction of the current of phase L2:
-I
L2
4 - third phase I
L3
current
5 - reversed direction of the current of phase L3:
-I
L3
0
4006 RW 0..5
Current on terminals 4, 6:
0 - first phase I
L1
current
1 - reversed direction of the current of phase L1:
-I
L1
2 - second phase I
L2
current
3 - reversed direction of the current of phase L2:
-I
L2
4 - third phase I
L3
current
5 - reversed direction of the current of phase L3:
-I
L3
2
4007 RW 0..5
Current on terminals 7, 9:
0 - first phase I
L1
current
1 - reversed direction of the current of phase L1:
-I
L1
4
