ND30-09D 52 User's manual
2 - second phase I
L2
current
3 - reversed direction of the current of phase L2:
-I
L2
4 - third phase I
L3
current
5 - reversed direction of the current of phase L3:
-I
L3
4008 RW 0,1 Input current range: 1 A or 5 A: 0 - 1 A, 1 - 5 A 1
4009 RW 0,1
Input voltage range:
0 – 3 x 57.7/100 V; 1 – 3 x 230/400 V (version 1)
0 – 3 x 110/190 V; 1 – 3 x 400/690 V (version 2)
1
4010 RW 0..18 Transformer primary voltage, two older bytes 0
4011 RW 0..65535 Transformer primary voltage, two younger bytes 100
4012 RW
1 ..
10000
Transformer secondary voltage x 10 1000
4013 RW
1 ..
20000
Transformer primary current 5
4014 RW 1 .. 1000 Transformer secondary current 5
4015 RW 0…2
Averaging time of the active power P Demand
apparent power S Demand
current I Demand
0 – 15, 1- 30, 2- 60 minutes
0
4016 RW 0.1
Synchronizationwith real-time clock
0 - no synchronization
1 - synchronization with a clock
1
4017 RW reserved
4018 RW reserved
4019 RW reserved
4020 RW Resistance of wires for the input T1 x 100 0
4021 RW Resistance of wires for the input T2 x 100 0
4022 RW reserved
4023 RW reserved
4024 RW 0…4
Energy counters erasing
0 – no changes, 1 – erase active energies
2 – erase reactive energies, 3 – erase apparent
energies, 4 – erase all energies
0
4025 RW 0.1
Erasing averaged parameters
P Demand, S Demand, I Demand
0
4026 RW 0.1 Min, max erasing 0
4027 RW
0.1
Erasing alarm signalization latch 0
4028 RW
Reserved
4029 RW
Reserved
4030 RW
0…4
Alarm output 1 - Logic tasks of the conditions 1,
2, 3
0 – C1
1 – C1 v C2 v C3
2 – C1 C2 C3
3 – (C1 C2) v C3
4 – (C1 v C2 C3
0
