3_oF – archiving is enabled when oFF type condition occurs on any
phase. It will be switched off only when all triggering condition are
disabled.
The value triggering an archiving in the series 3 archiving must be in
the range: 01-09 (acc. to Table 8). Archiving works with identical
thresholds of the Ar_L and Ar_H hysteresis for each phase.
Selection of the values on the alarm outputs, analog and archived:
Table 8
Value in
registers
Displaye
d element
Value type
Value of the needed for
calculations of percentage
corresponding to 100% of
the rated range.
01
U1
L1 phase voltage Un [V] *
02
I1
L1 phase wire current In [A] *
03
P1
L1 phase active power Un x In x cos(0°) [W] *
04
Q1
L1 phase reactive power Un x In x sin(90°) [Var] *
05
S1
L1 phase apparent power Un x In [VA] *
06
PF1
L1 phase power factor (PF) 1
07
tg1
tg factor of L1 phase
1
08
THD U1
L1 phase voltage THD** 100.00 [%]
09
THD I1
L1 phase current THD 100.00 [%]
10
U2
L2 phase voltage Un [V] *
11
I2
L2 phase wire current In [A] *
12
P2
L2 phase active power Un x In x cos(0°) [W] *
13
Q2
L2 phase reactive power Un x In x sin(90°) [Var] *
14
S2
L2 phase apparent power Un x In [VA] *
15
PF2
L2 phase active power factor PF 1
16
tg2
tg factor of L2 phase
1
17
THD U2
L2 phase voltage THD** 100.00 [%]
18
THD I2
L2 phase current THD 100.00 [%]
19
U3
L3 phase voltage Un [V] *
20
I3
L3 phase wire current In [A] *
21
P3
L3 phase active power Un x In x cos(0°) [W] *
22
Q3
L3 phase reactive power Un x In x sin(90°) [Var] *
23
S3
L3 phase apparent power Un x In [VA] *
24
PF3
L3 phase active power factor PF 1
25
tg3
tg factor of L3 phase
1
26
THD U3
L3 phase voltage THD** 100.00 [%]
27
THD I3
L3 phase current THD 100.00 [%]
