ND30-09D 63 User's manual
Table 19
Register
address
Operations Range Description Default
4300 RW 1…3
Luminosity level: 1 – Minimum,
2 – Medium, 3 - Maximum
3
4301 RW 0 .. 3600 Time to min. luminosity 0
4302 RW 0..7 Colors of pages 0
4303 RW
0x0001...
0x1FFF
Enabling displaying pages Bit0 – page 1,
Bit1 – page 2, ...Bit12 - page13
0x1FFF
4304 RW reserved
4305 RW 00..52 Page 1 display 1, U1 1
4306 RW 00..52 Page 1 display 2, U2 10
4307 RW 00..52 Page 1 display 3, U3 19
4308 RW 00..52 Page 1 display 4, f 37
4309 RW 00..52 Page 1 display 5, I1 2
4310 RW 00..52 Page 1 display 6, I2 11
4311 RW 00..52 Page 1 display 7, I3 20
4312 RW 00..52 Page 1 display 8, I avg 28
4313 RW 00..52 Page 2 display 1, U12 38
4314 RW 00..52 Page 2 display 2, U23 39
4315 RW 00..52 Page 2 display 3, U31 40
4316 RW 00..52 Page 2 display 4, U123 41
4317 RW 00..52
Page 2 display 5, P
30
4318 RW 00..52
Page 2 display 6, Q
31
4319 RW 00..52
Page 2 display 7, S
32
4320 RW 00..52 Page 2 display 8, PF avg 33
4321 RW 00..52 Page 3 display 1, P1 3
4322 RW 00..52 Page 3 display 2, P2 12
4323 RW 00..52 Page 3 display 3, P3 21
4324 RW 00..52
Page 3 display 4, P
30
4325 RW 00..52 Page 3 display 5, PF1 6
4326 RW 00..52 Page 3 display 6, PF2 15
4327 RW 00..52 Page 3 display 7, PF3 24
4328 RW 00..52 Page 3 display 8, PF avg 33
4329 RW 00..52 Page 4 display 1, P1 3
4330 RW 00..52 Page 4 display 2, P2 12
4331 RW 00..52 Page 4 display 3, P3 21
4332 RW 00..52
Page 4 display 4, P
30
4333 RW 00..52 Page 4 display 5, Q1 4
4334 RW 00..52 Page 4 display 6, Q2 13
4335 RW 00..52 Page 4 display 7, Q3 22
4336 RW 00..52
Page 4 display 8, Q
31
4337 RW 00..52 Page 5 display 1, THD U1 8
4338 RW 00..52 Page 5 display 2, THD U2 17
4339 RW 00..52 Page 5 display 3, THD U3 26
4340 RW 00..52 Page 5 display 4, THD U 35
4341 RW 00..52 Page 5 display 5, THD I1 9
4342 RW 00..52 Page 5 display 6, THD I2 18
4343 RW 00..52 Page 5 display 7, THD I3 27
