ND30-09D 65 User's manual
Register
address
Operations Range Description Default
4386 RW 00..47
The quantity displayed on the analog
indicator:
0-Off, 1-U1, 2-I1, ...47-T2
1
4387 RW
-1440 ..
1440
Bottom scale 0
4388 RW
-1440 ..
1440
Upper scale 1000
Table 20
Register
address
Opera
tions
Range Description Default
4400 R reserved
4401 R 0..65535 Identifier D9
4402 R 0..65535 Bootloader version x 100 -
4403 R 0..65535 Program version x100 -
4404 R reserved
4405 R 0..65535 Ordering codes -
4406 R 0..65535 Nominal voltage x10 577/2300
4407 R 0..65535 Nominal voltage x10 1100/4000
4408 R 0..65535 Nominal current (1 A) x 100 100
4409 R 0..65535 Nominal current (5 A) x 100 500
4410 R reserved
4411 R 0..65535
Seventh and sixth byte (B7.B6) of a serial
number, format B7:B6:B5:B4:B3:B2:B1:B0
-
4412 R 0..65535
Fifth and fourth byte (B5.B4) of a serial
number, format B7:B6:B5:B4:B3:B2:B1:B0
-
4413 R 0..65535
Third and second byte (B3.B2) of a serial
number, format B7:B6:B5:B4:B3:B2:B1:B0
-
4414 R 0..65535
First and zero byte (B1.B0) of a serial
number, format B7:B6:B5:B4:B3:B2:B1:B0
-
4415 R 0..65535 Status 1 Register – see description below 0
4416 R 0..65535 Status 2 Register – see description below 0
4417 R 0..65535 Status 3 Register – see description below 0
4418 R 0..65535 Status 4 Register – see description below 0
4419 R 0..65535 Status 5 Register – see description below 0
4420 R 0..65535 Status 6 Register – see description below 0
4421 R 0…65535
Fifth and fourth byte (B5.B4) of MAC address
of the meter, format B5:B4:B3:B2:B1:B0
-
4422 R 0…65535
Third and second byte (B3.B2) of MAC
address of the meter, format
B5:B4:B3:B2:B1:B0
-
4423 R 0…65535
The fifth and fourth byte (B1.B0) of MAC
address of the meter, format
B5:B4:B3:B2:B1:B0
-
4424 R 0…65535 Register status – description below 0
4425 R reserved 0
4426 R 0..152 Active import energy, two older bytes 0
