ND30-09D 74 User's manual
6320/8320 7660 R THD I min %
x x
6322/8322 7661 R THD I max %
x x
6324/8324 7662 R
HarU1[2] 2nd harmonic of L1
phase voltage
%
x
6326/8326 7663 R
HarU1[3] 3rd harmonic of L1
phase voltage
%
x
: : R :
: : R :
6420/8420 7710 R
HarU1[50] 50th harmonic of
L1 phase voltage
%
x
6422/8422 7711 R
HarU1[51] 51st harmonic of
L1 phase voltage
%
x
6424/8424 7712 R
HarU2[2] 2nd harmonic of L2
phase voltage
%
x x
6426/8426 7713 R
HarU2[3] 3rd harmonic of L2
phase voltage
%
x x
: : R :
: : R :
6520/8520 7760 R
HarU2[50] 50th harmonic of
L2 phase voltage
%
x x
6522/8522 7761 R
HarU2[51] 51st harmonic of
L2 phase voltage
%
x x
6524/8524 7762 R
HarU3[2] 2nd harmonic of L3
phase voltage
%
x x
6526/8526 7763 R
HarU3[3] 3rd harmonic of L3
phase voltage
%
x x
: : R :
: : R :
6620/8620 7810 R
HarU3[50] 50th harmonic of
L3 phase voltage
%
x x
6622/8622 7811 R
HarU3[51] 51st harmonic of
L3 phase voltage
%
x x
6624/8624 7812 R
Harl1U1[2] 2nd harmonic of
L1 phase current
%
x
6626/8626 7813 R
Harl1U1[3] 3rd harmonic of
L1 phase current
%
x
: : R :
: : R :
6720/8720 7860 R
Harl1U1[50] 50th harmonic of
L1 phase current
%
x
6722/8722 7861 R
Harl1[51] 51st harmonic of L1
phase current
%
x
6724/8724 7862 R
Harl2[2] 2nd harmonic of L2
phase current
%
x x
6726/8726 7863 R
Harl2[3] 3rd harmonic of L2
phase current
%
x x
: : R :
: : R :
6820/8820 7910 R
Harl2[50] 50th harmonic of L2
phase current
%
x x
