ODK4 QUICK REFERENCE GUIDE
Luminator Technology Group
5
Function of the ODK4 soft keys on the default screen are as follows (see 3-2
through 3-7 for basic operating instructions):
MENU – Used to access advanced programming options (some require a password).
RUN – Used to enter run number. (This function is determined by transit authority
programming.)
ROUTE – Used to enter route number. (This function is determined by transit authority
programming.)
P/R – Used to enable public relations message code entry. (This switch may be disabled
if public relation messages are not available.)
DESTA and DESTB – Used to enable respective destination message code entry for
message display change. (These switches are permanently enabled.)
All destination and public relations (P/R) messages can be set and viewed from the
ODK.
If enabled by transit authority programming, the emergency message is activated when
the operator toggles or depresses the vehicle’s emergency switch. When this switch is
activated, power is applied to the ODK emergency circuit and the emergency message
is displayed.
The sign system begins operation as soon as the vehicle is powered on. Examples of
basic ODK operating procedures follow (see 3-2 through 3-7).
3.2 Set Run Number
To set a Run Number, press RUN Key on the default screen (see Fig.3-2). Enter the
Run Number via the ODK number pad and then press ENTER (see Fig 3-3).
Figure 3-3. Enter Run Number Screen.
Note: To change a run number use the left/right arrow keys to hi-light a number and
press CLEAR (or press DEL to delete an entire string).
