ODK4 QUICK REFERENCE GUIDE
Luminator Technology Group
3
SECTION 2
ODK4 REMOVAL AND INSTALLATION
2.1 ODK4 Removal
a. Turn off power to the old ODK and sign system.
b. With a Phillips screwdriver, loosen two front bezel screws (one on each side of the
ODK). As each screw turns, the threaded cam latch behind the panel will loosen and
turn to allow removal.
c. When both screws are loosened, lift the ODK out of the panel and disconnect wiring
at its rear. Be sure wires are retained and not free to fall out of reach behind the
panel.
2.2 ODK4 Installation
The ODK4 comes complete and ready to use to include a factory installed destination
message listing per the relative agency.
a. With all power off, connect sign wiring to the ODK4:
• Connect power/data adaptor cable J1 connector to the ODK4 J1 (DB-9) connector
• Connect power/data adaptor cable P1 connector to existing front sign cable
• Connect power/data adaptor cable P2 connector to the existing dash sign cable (if
equipped)
• If equipped with a driver emergency/panic switch (or auxiliary equipment):
o Connect emergency adaptor cable P4 connector to the ODK4 J4 (DB-15)
connector
o Connect emergency adaptor cable P1 connector to the emergency/panic
switch cable provided by the OEM
o Connect emergency adaptor cable P2 connector to the auxiliary input
cable provided by the OEM (if equipped)
b. Put the ODK in position in the vehicle and secure by tightening the Phillips-head
screw on each side of the ODK. As the screw turns, a cam latch swings out behind
the vehicle panel to hold the ODK in position when the screw is tight.
c. The ODK4 is now ready for use. Refer to Section 3 for start-up and basic operation
instructions.
