Luminator ODK4 User Manual

ODK4 QUICK REFERENCE GUIDE
Luminator Technology Group
9
SECTION 4
CONFIGURE DISPLAY
4.1 Access Display Options
These screens are used to configure ODK operations and limits. Since these screens
change the operation of the sign and lighting systems and are intended for use by
trained personnel only, they are password protected.
Press MENU at the default screen (see Fig. 4-1) to access the Main Menu Screen (see
Fig. 4-2).
Figure 4-1. Default Screen
Figure 4-2. Main Menu Screen Figure 4-3. Access Configuration Screens
From the Main Menu Screen (see Fig. 4-2) press CONFG Key to open the Access
Configuration Screens window – this will generate a request for a password.
From Access Configuration Screens (see Fig. 4-3) enter password (factory default is
6511) then press ENTER to access the Configuration Menu Screen (see Fig. 4-4).
Figure 4-4. Configuration Menu Screen

Luminator ODK4 Specifications

General

Brand	Luminator
Model	ODK4
Category	Monitor
Language	English
