Lust ServoOne - Meanings of Leds

User Manual CANopen/EtherCAT
17
[Chapter 3]
3.3 Meanings of LEDs
There are 2 LEDs on each RJ-45 socket.
ACHTUN
G
W
ARNING
Ko
n
dens
a
tor
e
nent
-
ladeze
i
t > 3 mi
n
.
Betr
iebsan
leitung
bea
c
hten!
Capa
citor
disch
arge
time >
3
min
.
Pa
y at
t
ent
i
on
t
o th
e
oper
a
ti
o
n ma
nual
!
x
15
x
16
Figure Device with EtherCAT option
They have the following meanings:
LED Function Meaning
Upper
LED
Link LED
off = no Link
ð No connection with another user
on = Link
ð Connection with another user exists. Currently no data ex-
change.
toggle = activity
ð Flashing of the LED signals that data is being exchanged.
Lower LED Speed LED
off = 10 mbit/s
ð There is a connection with a transmission rate of 10 mbit/s.
on = 100 mbit
ð There is a connection with a transmission rate of 100 mbit/s.
Table LED meanings
