150
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
Choose the menu QoS>>Bandwidth Control>>Storm Control to load the
following page.
Figure 9-11 Storm Control
The following entries are displayed on this screen:
Storm Control Confi g
Port Select:
Click the Select button to quick-select the corresponding Port.
Select:
Select the desired Port(s) for Storm Control confi guration.
Port:
Displays the Port number of the Switch.
Broadcast Rate (bps):
Select the Bandwidth Limit for received Broadcast packets on the
Port. Any Broadcast packet traffi c exceeding the bandwidth will be
Discarded. Select Disable to disable the storm control function
for the Port.
Multicast Rate (bps):
Select the Bandwidth Limit for received Multicast packets on the
Port. Any Multicast packet traffi c exceeding the bandwidth will be
Discarded. Select Disable to disable the storm control function
for the Port.
