Luxul XMS-1024P User Manual

36
XMS-1024P
a: 14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450
LUX-UG-XMS-1024P Vers: 081314
Choose the menu System>>Access Control>>SSH Confi g to load the following page.
Figure 4-17 SSH Confi g
The following entries are displayed on this screen:
Global Confi g
SSH:
Enable or Disable SSH.
Protocol V1:
Enable or Disable SSH V1 support.
Protocol V2:
Enable or Disable SSH V2 support.
Idle Timeout:
Set the connection idle timeout time. The system will automatically
release the connection when the time has expired the default timeout
is 500 seconds.
Max Connect:
Set the maximum number of allowed connections to the SSH Server. No new
connection will be allowed when the number of the connections reaches the
maximum, the default value is 5.
Key Upload
Key Type:
Select the type of SSH Key to upload, the Switch supports three types: SSH-1
RSA, SSH-2 RSA and SSH-2 DSA.
Key File:
Select the desired key fi le to upload.
Upload:
Click the Upload button to upload the desired key fi le to the Switch.

Luxul XMS-1024P Specifications

General

Ports	24
Power over Ethernet (PoE)	Yes
Total PoE Power Budget	370W
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	2
Port Speed	10/100/1000 Mbps
Form Factor	Rack-mountable
PoE Ports	24
PoE Standard	802.3af/at
MAC Address Table	8K
Jumbo Frame Support	9KB
Power Supply	Internal
Input Voltage	100-240VAC, 50/60 Hz
Humidity	10% to 90% non-condensing
Operating Temperature	0 to 40°C (32 to 104°F)
