Lytro Illum User Manual

19
Inserting an SD card
Open the port cover and insert a SD, SDHC, or SDXC card into the SD card slot. For the rst time use of
the camera, 2GB of free space is required on the SD card. This free space is required for the Pairing data
(see Transferring the Pairing data in this section). Close the port cover.
Using the set-up assistant
The rst time the camera is turned on, there is a walk through to set-up the camera, where you select the
language for the camera to use, select time zone, set the date and time, and transfer the Pairing data (see
next section). The camera will then give a very brief overview of its most unique controls and features.
Transferring the Pairing data
As part of the walk-through to set up the camera, Pairing data is transferred to the SD card. The Pairing
data is required by the Lytro Desktop to optimally process pictures, and will be automatically copied off of
the SD card by the Lytro Desktop the rst time pictures are imported from that card.
The Pairing data requires approximately 2GB of free space on the SD card. Do not reformat or delete the
contents of the SD card until the Pairing data has been transferred to the Lytro Desktop.
The Pairing data may be manually transferred at a later time (see Transfer Pairing Data to SD Card).
Powering on and off
Briey press the power button to turn the camera on. To power off, briey press the power button again.

Lytro Illum Specifications

General

Megapixel	- MP
Camera type	Bridge camera
Sensor type	CMOS
Image stabilizer	No
Image sensor size	1/1.2 \
Supported aspect ratios	3:2
Maximum image resolution	2450 x 1634 pixels
Image sensor size (W x H)	10.82 x 7.52 mm
Still image resolution(s)	2450 x 1634
Digital zoom	- x
Optical zoom	8 x
Focal length range	9.5 - 77.8 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	30 mm
Focus adjustment	Auto
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	80, 3200
Light exposure modes	Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	32 s
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	4 \
Display resolution	480 x 800 pixels
USB version	3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	2, 10 s
Camera file system	RAW
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Power source type	Battery
Battery voltage	3.7 V
Battery capacity	3760 mAh
Material	Aluminium, Magnesium
Product color	Black
Sustainability certificates	RoHS
Cables included	Micro-USB
Bundled software	Lytro Desktop
F-number (relative aperture)	2
Storage temperature (T-T)	2450 x 1634 °C

Weight and Dimensions

Depth	166 mm
Width	145 mm
Height	86 mm
Weight	940 g
Weight (including battery)	1029 g
