Lytro Illum User Manual

2
Table of Contents
Introducing the Lytro ILLUM 6
Benets of the Light Field 6
Learning to use Lytro ILLUM 6
Quick Reference Guide 8
In the box 9
Product Requirements 9
Touchscreen Capture Mode 10
Image View Area 11
Information Bar 12
Menu Bar Page 1 13
Menu Bar Page 2 14
Menu Bar Page 3 15
Playback Mode, Menu Bar Page 1 16
Playback Mode, Menu Bar Page 2 17
Getting Started 18
Charging the battery 18
Inserting the charged battery 18
Inserting the strap rings 18
Inserting an SD card 19
Using the set-up assistant 19
Transferring the Pairing data 19
Powering on and off 19
Capture Mode 20
Camera Control Behaviors 21
Touchscreen layout in Capture Mode 22
Capture Mode, Image View Area 24
Capture Mode, Information Bar 26
Capture Mode, Menu Bar Page 1 28
Capture Mode, Menu Bar Page 2 30
Additional touch control icons 32
Tapping the screen to focus 33
Hiding /displaying the Menu / Information Bar 34
Choosing an exposure mode 35
Setting the ISO 38

Lytro Illum Specifications

General

Megapixel	- MP
Camera type	Bridge camera
Sensor type	CMOS
Image stabilizer	No
Image sensor size	1/1.2 \
Supported aspect ratios	3:2
Maximum image resolution	2450 x 1634 pixels
Image sensor size (W x H)	10.82 x 7.52 mm
Still image resolution(s)	2450 x 1634
Digital zoom	- x
Optical zoom	8 x
Focal length range	9.5 - 77.8 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	250 mm
Minimum focal length (35mm film equiv)	30 mm
Focus adjustment	Auto
Light metering	Evaluative (Multi-pattern)
ISO sensitivity	80, 3200
Light exposure modes	Manual, Shutter priority AE
ISO sensitivity (max)	3200
ISO sensitivity (min)	80
Light exposure control	Program AE
Auto Exposure (AE) lock	Yes
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	32 s
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	4 \
Display resolution	480 x 800 pixels
USB version	3.2 Gen 1 (3.1 Gen 1)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Self-timer delay	2, 10 s
Camera file system	RAW
Mac operating systems supported	Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Power source type	Battery
Battery voltage	3.7 V
Battery capacity	3760 mAh
Material	Aluminium, Magnesium
Product color	Black
Sustainability certificates	RoHS
Cables included	Micro-USB
Bundled software	Lytro Desktop
F-number (relative aperture)	2
Storage temperature (T-T)	2450 x 1634 °C

Weight and Dimensions

Depth	166 mm
Width	145 mm
Height	86 mm
Weight	940 g
Weight (including battery)	1029 g
